Overlap steady arm, rigid, G1" curved with eye and plain bearing, L = 1400 mm, with thread M16, SST

D2844-01

Overlap steady arm, rigid, G1" curved with eye and plain bearing, L = 1400 mm, with thread M16, SST

Dimensions

Ø1: 16 mm
Ø2: M16
A: 18 mm
Ø3: 33.7 mm
L: 1400 mm
B: 353 mm

Material and weight

Material: SST

Loads

Breaking load F: 2.5 kN

Comments

- Minimum order quantity on request
